- Pure electric drive, green environmental protection, better benefits: easily cope with the crisis of rising oil prices, bring long-term sustainable green development to enterprises;
- Ultra-large capacity battery pack, ultra-long life: fast charging 1.6 hours, normal working conditions of up to 6 to 10 hours, ultra-large capacity lithium iron phosphate battery, safe and durable, ultra-long warranty, enjoy worry-free;
- Battery package design, safer: integrated battery package design, battery system waterproof, dustproof, safe and reliable;
- Variable system, more energy saving: effectively avoid energy loss, system energy saving up to 10%.
4280DE
Operating Weight:
24,000 kg
Blade Width:
4,270 mm
Drawbar Pull:
123 kN
4280DE
Unit：：：
- Metric
- U.S
Product Features
4280DE
4280DE
4280DE
4280DE
Specifications
| Operating Weight | 24,000 kg |
| Standard Moldboard Size | 4,270*645*19 mm |
| Rated Storage Energy | 423 kWh |
| Drawbar Pull | 123 kN |
| Steering Angle | ±50° |
| Front Axle, Wheel Lean Angle | ±18° |
| Front Axle Oscillation | ±16° |
| Length (Standard configuration) | 9,980 mm |
| Overall Width Over Tires | 2,860 mm |
| Cab Height | 3,530 mm |
| Wheelbase | 6,700 mm |
| Middle and Rear Wheel Wheelbase | 1,632 mm |
| Ground Clearance | 422 mm |
| Minimum Turning Radius | 7,500 mm |
| Download Brochure |
※For reference only.
